Angulo Window
Angulo Window
Aluminum Window Frame Energy-Efficient Inward Opening Tilt-and-Turn Windows
The Aluminum Inward Opening Tilt-and-Turn Window is designed for modern buildings that require flexibility, safety, and performance. Made from high-quality aluminum, it offers excellent strength, durability, and corrosion resistance. The inward opening function allows easy cleaning, while the tilt position provides secure and controlled ventilation. With good thermal and sound insulation, this window enhances indoor comfort and energy efficiency, making it ideal for both residential and commercial applications.
| Test Description | Results (High Spec) |
|---|---|
| Class | CW-PG50 |
| Water Penetration Resistance | 720Pa |
| Air Leakage Resistance | +75 Pa: 0.11 L/s·m² | -75 Pa: 0.13 L/s·m² |
| Uniform Load Deflection | ±2400Pa |
| U Factor (Btu/Hr-Ft2-F) | 0.15 |
| Test Description | Standard Results |
|---|---|
| Class | CW-PG40 |
| Water Penetration Resistance | 580Pa / 360Pa |
| Air Leakage Resistance | +75 Pa: 0.11 L/s·m² | -75 Pa: 0.08 L/s·m² |
| Uniform Load Deflection | ±1920Pa |
| U Factor (Btu/Hr-Ft2-F) | 0.15 - 0.17 |
